Description
The scroll is designed and built for maximum efficiency using four points method.
Casing is made of galvanized steel or ST-37 coated with 3 layers of epoxy paint. The thickness varies depending on the model from 1 to 3 mm.
Impeller is made of ST-37in-house. It is dynamically balanced and coated with 3 layers of epoxy paint.
Chassis is made of L or U profiles.
Electric motor is chosen from the best quality E.U made motors available in the local market.
Bearings and V Belts are selected according to the list attached and are either German or Japanese made. The V Belts are made by Tasmeh Melli or imported from korea.
Accessories IHC’s standard product comes with On/Off switch, guard for the belt drive, motor cover, bearing cover, protection grid at the outlet/inlet flange.
Dimensions of Chassis for SFU 225 to 999
|
Model |
A |
B |
P1 |
P2 |
P3 |
P4 |
P5 |
P6 |
P7 |
P8 |
|
SFU-225
|
650
|
150
|
80
|
-
|
80
|
115
|
80
|
-
|
80
|
75
|
|
SFU-315
|
850
|
210
|
100
|
425
|
100
|
145
|
100
|
425
|
100
|
105
|
|
SFU-400
|
950
|
250
|
100
|
475
|
100
|
165
|
100
|
475
|
100
|
125
|
|
SFU-500
|
1150
|
310
|
100
|
575
|
100
|
195
|
100
|
575
|
100
|
155
|
|
SFU-630
|
1300
|
410
|
100
|
650
|
100
|
245
|
100
|
650
|
100
|
205
|
|
SFU-710
|
1400
|
450
|
100
|
700
|
100
|
265
|
100
|
700
|
100
|
225
|
|
SFU-900
|
1700
|
565
|
200
|
850
|
200
|
323
|
200
|
850
|
200
|
283
|
|
SFU-999
|
1800
|
635
|
200
|
900
|
200
|
357
|
200
|
900
|
200
|
317
|
Dimensions of SFU (225-999)
|
Model |
A |
B |
B’ |
C |
D |
D’ |
E |
E’ |
L |
M |
N |
X |
Y |
|
SFU-225
|
650
|
230
|
285
|
460
|
150
|
200
|
300
|
350
|
420
|
250
|
30
|
210
|
185
|
|
SFU-315
|
850
|
290
|
380
|
630
|
200
|
260
|
420
|
480
|
540
|
340
|
30
|
250
|
250
|
|
SFU-400
|
950
|
330
|
410
|
770
|
240
|
300
|
540
|
600
|
650
|
420
|
30
|
240
|
310
|
|
SFU-500
|
1150
|
390
|
490
|
950
|
300
|
360
|
635
|
695
|
840
|
530
|
30
|
370
|
390
|
|
SFU-630
|
1300
|
490
|
590
|
1200
|
400
|
480
|
785
|
865
|
1030
|
640
|
30
|
440
|
480
|
|
SFU-710
|
1400
|
540
|
660
|
1340
|
440
|
520
|
895
|
975
|
1180
|
730
|
30
|
520
|
550
|
|
SFU-900
|
1700
|
645
|
800
|
1680
|
560
|
640
|
1130
|
1215
|
1440
|
780
|
30
|
620
|
670
|
|
SFU-999
|
1800
|
730
|
975
|
1850
|
640
|
715
|
1240
|
1320
|
1540
|
880
|
30
|
680
|
730
|
